Cross Reference Numbers: 4960837, AP7012980, EAP16546780, PS16546780
Fitment: LG front load electric and gas dryers plus LG WashTower units and select Kenmore Elite dryers that use the revised lint filter design (partial model list below)
Type: Aftermarket replacement lint screen built to OEM-style dimensions (not a Genuine LG OEM part unless stated in title)
Key Features
-
Direct Slide-In Fit for LG dryers using ADQ56656403, seats into the original lint trap guide with no cutting or modification
-
ABS Plastic Frame with Fine Mesh Screen, no top ears and no felt seal — this is the revised LG design, narrower than ADQ56656401 and smaller than 5231EL1003B
-
Traps Lint Fibers and Debris from tumbling clothes, keeping them out of the exhaust duct and heater housing
-
Restores Airflow and Drying Efficiency by keeping the screen path clear, reducing long dry cycles, overheating and lint marks on fabrics
-
Helps Reduce Fire Risk from packed lint buildup in the screen slot and rear vent
-
Tool-Free Install in under 1 minute, just pull the old screen out and slide the new one in
-
Approx Size 11.2 x 10.9 inches (284 x 276 mm), gray or white frame depending on batch, matches common LG DLEX4000 / DLGX4000 series and newer WashTower filter housings
What It Fixes
Replace your ADQ56656403 lint filter if you see:
-
Torn or ripped mesh screen
-
Cracked or warped plastic frame
-
Old filter has no top ears and no felt edge, and the new slot is shaped for this revised version
-
Clothes come out with lint specks
-
Dryer takes too long to dry or shuts off early
Compatible LG Models (Partial List)
DLEX4000B, DLEX4000W, DLEX4000V, DLEX4005W, DLEX4050B, DLEX4050W, DLEX4200B, DLEX4200W, DLEX4270V, DLEX4300W, DLEX4500B, DLEX4500W, DLEX4600W, DLEX4700B, DLEX4700W, DLEX4800W, DLEX4801W, DLEX4900W, DLEX5000W, DLEX5000V, DLEX5500W, DLEX5700V, DLEX5800W, DLEX5801W, DLEX6001W, DLEX6500B, DLEX6500W, DLEX7000W, DLEX7100W, DLEX7177WM, DLEX7600WE, DLEX7800WE, DLGX4001B, DLGX4001W, DLGX4001V, DLGX4200B, DLGX4200W, DLGX4500B, DLGX4500W, DLGX4700B, DLGX4700W, DLGX4800W, DLGX4801W, DLGX4900W, DLGX5001W, DLGX5500W, DLGX5700V, DLGX5800W, DLGX5801W, DLGX6001W, DLGX6500B, DLGX6500W, DLGX7000W, WKGX201HBA, WKE100HWA, DLGX3571V and more
Compatible Kenmore Elite Models (Partial List)
79680512900, 79680518900, 79681022900, 79681028900, 79681182310, 79681282310, 79681382410, 79681472210, 79681532210, 79681548210, 79681722010, 79682192900, 79690512900, 79691022900, 79691182310, 79691548210 and more
If your exact model is not listed, send us your dryer model number before ordering and we will confirm fitment.
Important Fitment Note
ADQ56656403 is the revised LG design. If your original filter has top ears or a felt rim seal, this part will not seat correctly — you likely need ADQ56656401 (with ears) or 5231EL1003B (with felt). If your dryer uses the newer lint guide MCK49049101 and guide MEA49050001, replace all three together. Always measure your old screen before ordering.
Specifications
-
Part Number: ADQ56656403
-
Product Type: Dryer Lint Filter Screen
-
Material: ABS plastic frame, fine mesh screen
-
Color: Gray or white frame
-
Approx Size: 11.2 x 10.9 x 1.0 inches
-
Package: 1 x Lint filter screen
Installation Note
Unplug the dryer before service. Pull the old lint screen straight up from the front slot, clear loose lint in the channel and on the guide rails, then slide the new filter down until fully seated. Clean the screen after every load to keep airflow clear and avoid overheating.
Compatibility Disclaimer
This is an aftermarket replacement part. LG, Kenmore and related model names are used only to indicate compatibility. Not affiliated with or endorsed by LG Electronics or Kenmore.
